when the glue is inconsistent, it is mainly caused by the pressure cylinder or the air pressure instability of the stored fluid. 1. the inlet pressure regulator should be set at 10 to 15 psi lower than the lowest pressure in the plant. the pressure used in the cylinder should be above the pressure in the middle of the regulator. avoid using pressure between the pressure gauge and low pressure. section. 2, the valve control pressure should be at least 60psi to ensure the stability of the glue. 3. finally, the glue time should be checked. if it is less than 15/1000 seconds, the glue will be unstable. the longer the glue is, the more stable the glue is.

the automatic vacuum double-liquid glue filling equipment is designed for the glue filling process of completely removing bubbles. putting the product under vacuum environment is the necessary condition for reaching the bubble-free filling. the vacuum chamber is designed as an independent and complete unit. it is combined with the “material pretreatment and conveying unit” to show the flexibility and flexibility of the configuration. it is especially important to realize the flexible configuration of the pipeline. use tempered glass and alec sheet to synthesize the window, and seal the joint at the interface to ensure the vacuum degree and monitor the filling process in real time. moreover, the vacuum value can be displayed and detected in real time, thereby eliminating the possibility of any bubble generation and the influence of moisture or the external environment, achieving high-quality glue filling from beginning to end.

first, the dispenser is generally a small amount of precise dispensing, and the glue filling machine is generally a large amount of glue filling. second, the dispenser is generally suitable for small products or electronic components, which are relatively precise; the products of the glue filling machine are generally large.

the two-liquid glue filling machine consists of two storage tanks for two glue pumps. after mixing and mixing, there is an essential difference between the type of glue filling machine and the ordinary glue filling machine. use the pump body pressure to control the glue. the unit features automatic configuration and automatic adjustment. the double-filler is a potting machine developed for the treatment of two-component glue, quantitative dispensing of multi-component fluids, and ab glue. this type of glue filling machine also has a static mixing valve, which is a two-liquid filling machine with a large discharge volume! in the research of the glue filling machine, the characteristics of the vacuum glue filling machine are: positioning accuracy, high precision, small error, and other three characteristics. these three characteristics are that the vacuum glue filling machine is the first in the same type of glue filling machine. an important feature. the vacuum glue filling machine has

glue: single-component glue for single-component ordinary glue, double-layer glue-filling machine for ab glue.glue filling process: ordinary filling glue using semi-automatic glue filling machine (such as foot control), precise positioning line is selected desktop, three-axis, drawing circle and other automated function glue filling machine. the automation function of the dispenser is actually an auxiliary function of the glue filling machine to control the glue.

please acknowledge the glue cleaner with the glue supplier. close the bottom valve of the ab drum.the operating equipment is glued out, and the glue remaining in the rubber valve, high-pressure teflon tube and ab pump is played out. it can be investigated to change the glue amount of the rubber valve outlet, and it is judged that the internal glue has been drained.close the total power of the equipment.

weigh the glue that flows out of the first time with the electronic scale every day, and compare the set values.when the a/b barrel is glued, the supervisor is required to be present. avoid adding wrong glue. the storage tank and pipe must be sealed. regularly add grease to gears and static heads. the gears are refueled at least once a week. clean the filter once a week.

four criteria: small point - small needle, low pressure, short time large point - large needle, large pressure, long time thick glue - oblique needle, large pressure, set time according to need aqueous liquid - small needle, less pressure, set time as needed

the system adopts multi-level pressure sensor to monitor and control the pressure variation of the pipeline.(2.12s-2.44s) hollysys provides a two-component metering system with precision screw metering and closed-loop pressure sensor to monitor the feeding and discharging of screw, which guarantees the accuracy and reliability of screw. the accuracy of mixing and discharging of glue is less than ( 1%) and the software algorithm of hollysys is used to make 1:1-10:1 self-switching and provide static mixing and dynamic. two mixing modes of state mixing.

the system adopts multi-level pressure sensor to monitor and control the pressure variation of the pipeline.(2.12s-2.44s) hollysys provides a two-component metering system with precision screw metering and closed-loop pressure sensor to monitor the feeding and discharging of screw, which guarantees the accuracy and reliability of screw. the accuracy of mixing and discharging of glue is less than ( 1%) and the software algorithm of hollysys is used to make 1:1-10:1 self-switching and provide static mixing and dynamic. two mixing modes of state mixing.

the system adopts multi-level pressure sensor to monitor and control the pressure variation of the pipeline.(2.12s-2.44s) hollysys provides a two-component metering system with precision screw metering and closed-loop pressure sensor to monitor the feeding and discharging of screw, which guarantees the accuracy and reliability of screw. the accuracy of mixing and discharging of glue is less than ( 1%) and the software algorithm of hollysys is used to make 1:1-10:1 self-switching and provide static mixing and dynamic. two mixing modes of state mixing.
